Mechanical |
|
|---|---|
| Frame | Aluminum Alloy Material, SS8MD New Eel Frame |
| Wheel Size | 650B 36H Front and Rear |
| Fork | NEX DS 700C Non-Lockout / Teeth Headtube: ф28.6×ф25.4 *183MM / Disc Brake / Travel Distance: 63MM |
| Handlebar | PROMAX HB-T305 17.5（Inner Size）*25.4*W620*162*9*H60 P48 ENC |
| Stem | PROMAX MQ-565S |
| Seatpost | SP-252 28.6*400mm |
| Seat Clamp | Alloy Quick Release 28.6mm |
| Saddle | VELO VL-6100 GEL |
| Shifters | Single Speed Drive Simplicity / 3 or 5 Level PAS |
| Derailleur | SHIMANO ACERA ARDM360SGSL / Black |
| Rims | POWER CIRCLE P23DM 36H Double Wall Alloy |
| Hubs | MODUS JA159F-DSE-QR |
| Hubs | MODUS JA259R-DSS 3/8*13*36*135*190 |
| Spokes | 13g 2.2mm F / 12g 2.6mm R Stainless Steel 265mm/267mm |
| Tyres | Schwalbe Super Moto-X 27.5in x 2.4in Tyres |
| Cranks | PROMAX E44PP/32 170MM 44T |
| Pedals | YONGHUA 8X |
| Chain | KMC Z51/RB/140L |
| Brakes Front | Tektro Hydraulic Disc Brakes |
| Brakes Rear | Tektro Hydraulic Disc Brakes |
| Brake Levers | Tektro Hydraulic Brakes Levers |
| Mudguards | Black Plastic 650B x 65mm |
| Stand | Chain Stay Side Mount Adjustable Alloy |
| Rear Rack | Alloy 650B / 700C Pannier Compatible |
Electrical |
|
|---|---|
| Motor | 250W Mivice Rear Hub Motor – Dayco Belt Drive |
| Efficiency | Greater than 80% |
| Torque | 95Nm – Integrated Torque Sensor |
| Controller | Mivice – 15Amp Digital Internal Integration |
| Battery | 36V 475mWh (13.2Ah) Samsung Lithium Battery |
| Battery Life | Up to 800 recharges from flat |
| Battery Weight | 2.4kg |
| Display Panel | Full Colour KD86 With USB Port |
| Operation Controls | Left Handlebar Mivice Compatible |
| Pedal Activation | Mivice Motor Integration |
| Light Front | BUCHEL LED 51252712 Static Illumination |
| Light Rear | BUCHEL LED 51254523 Static Illumination |
| Charger | Sans 36V 2Amp Lithium AU Compliant |
| Main Cable | JULET 1T5 Waterproof Quick Release |
| Audible Warning | HONKA HOOTA Black |
| Max Speed | 25kmh |
| Max Range | 80km 1:1 Pedal Assist |
| Bicycle Weight | 24kg incl battery |
Sizing |
|
|---|---|
| Seat Tube | 450mm |
| Step Over | 450mm |
| Max Seat Height | 1080mm |
| Min Seat Height | 850mm |
| Length | 1820mm |
| Width | 670mm |
