| Article number: | 349B |
| Quantity: | 1 |
Mechanical |
|
|---|---|
| Frame | 6061 Grade Alloy |
| Wheel Size | 26” 36H Front and Rear |
| Fork | Uding Alloy Suspension |
| Handlebar | ZOOM NR-AL-196 W640 φ31.8 |
| Stem | TDS-C269-8 E:90 |
| Seatpost | PROMAX 27.2 x 300mm |
| Seat Clamp | Alloy Quick Release 27.2mm |
| Saddle | KNUS KS7068 |
| Shifters | SHIMANO ASLM3157RC-7 |
| Derailleur | SHIMANO ALTUS |
| Rims | PARWEIER 700 x 40c 36H Double Wall Alloy |
| Hubs | MODUS Aluminium |
| Spokes | 13g 2.2mm Stainless Steel |
| Tyres | Chaoyang 26 x 2.1 |
| Cranks | PROMAX E44PP/32 170MM 44T |
| Pedals | VP536C |
| Chain | KMC Z5GY |
| Brakes Front | TEKTRO Aries Mechanical Disc |
| Brakes Rear | TEKTRO Aries Mechanical Disc |
| Brake Levers | FuAiXing-S3/4 Locking With Power Cut Off |
| Mudguards | Black Aluminum Alloy |
| Stand | Chain Stay Side Mount Adjustable Alloy |
| Rear Rack | Alloy 26” Pannier Compatible |
Electrical |
|
|---|---|
| Motor | 250W Rear Hub Drive Motor |
| Controller | 15Ah LISHUI Brushless LSW1155-59M |
| Battery | SAMSUNG 36V 13.2Ah |
| Battery Life | Up to 800 recharges from flat |
| Battery Weight | 2.4kg |
| Display Panel | KEY DISPLAY KD86 |
| Operation Controls | Left Handlebar KD86 Compatible |
| Twist Grip Acc Assy | Wuxing 158X.T / HT406 Slimline |
| Pedal Activation | Yonglin 12 Magnet Left Crank Mount |
| Light Front | Spamning LED HL1900 Static Illumination |
| Light Rear | Yonglin LED 69E Static Illumination |
| Charger | Keyu 36V 2Amp Lithium AU Compliant |
| Main Cable | JULET 1T5 Waterproof Quick Release |
| Audible Warning | HONKA HOOTA Black |
| Max Speed | 25kmh |
| Max Range | 80km 1:1 Pedal Assist |
| Bicycle Weight | 24kg incl battery |
Sizing |
|
|---|---|
| Length | 1760mm |
| Width | 690mm |
| Max Seat Height | 1050mm |
| Min Seat Height | 800mm |
| Step Over | 400mm |
